Sanwa OBSF 30mm Pushbuttons Vermillion

×
Rating
Price:
$2.95 (USD)
SKU
SANWA-OBSF-30-VER
Weight
0.36 Ounces
Availability
Ships within 1-2 business days
Shipping
Calculated at checkout
Max Qty
16 unit(s)

Why is there a quantity limit? Learn more. new-window-icon.png


Quantity:
Description
Reviews
Videos
Warranty
Other Details
  • Product Description

    The SANWA OBSF series is considered the standard in high-quality Japanese arcade and commercial joystick pushbuttons. These buttons are compatible with the MadCatz line of FightSticks, Qanba FightSicks and Hori Fightsticks.  These buttons are specifically for custom joysticks that use a metal control panel.

    Sanwa's 30mm button snap right into most configurations, and offer the best reaction time, smoothest and quietest of any button.  The buttons are available in a variety of colors for great customization. Additionally, you can swap out the button plungers for even more customization.

    Bundle with Silencer 30mm Foam Washers and Save!

    Silencer Foam Washer Silencer installed in Sanwa pushbutton
    Silencer installed into Seimitsu screwbutton Silencer installed in Seimitsu PS-15 Low Profile (tabs snipped to fit)

    Silencer is our 1mm-thick foam washer that helps to dampen the loud sounds common with tapping on the button plunger.  It conforms to the internal housing of many Sanwa or Seimitsu-style 30mm pushbuttons.

    Known compatibility:

    SanwaSeimitsuCrownHori

    Click "Add to Order" to save 40% off retail of a Silencer foam washer for each button you purchase.

    Silencer Installation

    installing the Silencer foam pads into a Sanwa or Seimitsu pushbutton is straightforward.  Place the washer - plastic film side down - into the button housing.  Align the small tabs so that they stick out of the holes on each side of the housing.  For Seimitsu PS-15, and Hori Hayabusa low profile pushbuttons, snip the tabs off with scissors and place into the housing.

    24 vs 30mm

    When processing orders, a frequent mistake we found among new players is choosing the wrong size for action buttons, such as punch and kick.

    Within the fighting game genre, Japanese arcade buttons commonly consist of two diameter sizes: 24 millimeter and 30 milllimeter (mm). In most configurations, 30mm represents your action button.  These are front facing, appearing most prominent on your Fightstick control panel.  Option button, such as "Start", "Select", or more recently "Option", "Touch", or "Share" are usually 24mm.

    UPDATE: Owners of Neo Geo AES Joysticks will need 24mm pushbuttons instead of 30mm (Thanks SRK's DEZALB)

    Below is a visual representation of a common Fightstick control panel.  Throughout this article, we will mark 24mm in green, and 30mm in Orange.

    Common joystick configuration

    Checking the Proper Size

    button-30mm.pngAnother way that players can misinterpret the pushbutton size is by measuring the pushbutton plunger.  Have a look at the diagram at right.

    The plunger - the part that you press down to represent an input - is 25mm or a bit smaller in most 30mm pushbuttons.  Often this leads to the conclusion that one needs a 24mm button and not 30mm.

    Similarly measuring the button rim can lead to confusion, as it is intentionally larger than the button hole it is placed in.  You don't want to use these measurements.  Instead, review the button housing diameter, or the hole the button will be placed in.  You can do this with a caliper - a digital caliper is often quite helpful for this and other arcade-related projects.

    Control Panel Configuration

    Most Fightsticks from MadCatz, Hori, Qanba, and similar will use these two sizes.  How the buttons are used will depend on the model joystick that you own. Over time, we'll provide example configurations for specific popular Fightstick models and arcade cabinets using the color key for 24mm (green) and 30mm (orange).  We'll also expand the key for future models if another size is introduced, and we offer for sale.



    24vs30mm Hitbox Example
    HRAP and Qanba Model Configuration
    MadCatz Model Configuration
    Qanba Q1 and Mayflash/Venom Model Configuration

  • Product Reviews

    ×

    Write A Review

    1. Closer to red than pictured

      Sanwa Vermillion buttons are perfect for matching with the default red that Seimitsu uses or getting closer to the more vibrant red used in classic arcade cabinets for balltops, etc. I use vermillion buttons for my Neo Geo layouts. Sanwa's default 'red' is too dark. on Dec 18th 2020

    2. Buttons work fine but

      Buttons work like you'd expect sanwas to work. However if you plan to install these in a rap n like i did, you should know that i had to use a good amount of force to actually fit them in the button holes. There are a few small indents on the side of the button that actually collide with edge of the button hole. I don't know if that was just this specific color or if it's on all obsf's though. on Sep 23rd 2020

    3. Working perfect

      Working perfect on Nov 8th 2017

    4. good buttons

      they good on Feb 10th 2017

    5. In a certain light, this and orange look nearly identical

      Solid Sanwa buttons, but beware the hue if you're expecting something with a redder tone or a brighter tone. In person, these buttons are often difficult to distinguish from plain orange. So, if you're thinking about a Yellow, Orange, Vermillion, Red setup, know that it'll really look like Yellow, Orange, Slightly darker Orange, and Dark red. Basically, Sanwa should call this "Orange" and their current orange should be called "Light Orange," if that makes sense... on Sep 25th 2015

×
×
